Description
Transducers
- Tweeter : 1-inch Compression Driver
- Woofer :
- 16cm paper cone / Tangential suspension / Neodymium Eighteen Sound
- Eighteen Sound 13cm Polypropylene Cone (Face to Face)
Specifications
- Dimensions (H x D x L) : 920 x 210-290 x 320 mm
- Weight : 28 kg
- Terminals : 5μ Silver Plated Pure Copper / Atlantis Lab Original
- Tips : Atlantis Lab Original designed by Pann Audio
- Internal wiring : Esprit Audio
- Finish: Black or white imitation leather, elegantly combined with oak
- Warranty : 7 years
- Running-in : 100 h
Directions for use
Adjustable Bass Reflex Event
- Factory setting : 14.3 cm
- Fitting options : Lengths of 14.5 cm, 16.1 cm or 17.0 cm can also work well depending on your room.
Speaker Placement
- Can stand being against the wall
