Description
Transducers
- Tweeter : Eighteen Sound 1-inch Neodymium Compression Driver with horn, covering 6 kHz – 20 kHz
- Midrange Driver : 1.4-inch Compression Driver with Eighteen Sound diaphragm, covering 400 Hz – 6 kHz
- Woofer : 38cm Eighteen Sound Neodymium paper cone, covering 30 Hz – 400 Hz
Specifications
- Dimensions (H x D x L) : 1,140 x 510 x 345 mm
- Weight : 60 kg
- Terminals : 5μ Silver Plated Pure Copper / Atlantis Lab Original
- Tips : Atlantis Lab Original designed by Pann Audio
- Internal wiring : Esprit Audio
- Finish: Black or white imitation leather, elegantly combined with oak
- Warranty : 7 years
- Running-in : 100 h
Instructions for Use
Adjustable Bass Reflex Event
- Factory setting : 14.2 cm
- Fitting options : Lengths of 10.3 cm, 11.0 cm, 12.3 cm, 13.3 cm, or 14.6 cm for optimal results depending on your room.
Speaker Placement
- Can stand being against the wall
